FILTER MATERIAL
Either Filterballs or sand can
be used as a filter material.
Filterballs (Art. 1069): Besides a
high filtration capacity (down to 1
micron), Filterballs are water-saving
as you do not need to continuously
backwash. Instead, you can simply
wash the Filterballs in the washing
machine (without soap), or by hand,
when the season is over. Compared
to other filter materials Filterballs
have a minimal water resistance,
which gives a higher water flow.
This means that the filter system
can circulate all the pool water
faster, which in turn means less
energy consumption. Another great
advantage is the light weight of the
Filterballs. This is great news for
your back when it comes to emptying
the filter tank! 100g Filterballs are
equivalent to an entire 3.57 kg sand.
Filter sand (Art. 1760): Sand is
historically the most common filter
material. And with good reason. The
natural material picks up particles
down to 40 micron. On the other
hand, sand, and especially wet
sand, is mega heavy. Therefore, it is
recommended that the filter system is
located in its intended position before
the tank is filled with sand. Sand also
requires ongoing backwashing, a
minimum of 2-4 times per month, in
order to clean the sand. This means
that you use more water when you
choose sand as a filter material. In
a pool with 30-40,000 litres of water,
between 180 and 240 litres of water
is used per backwash.
Powerful pump and large
filter tank
The system comes with a powerful
pump that is proportionate in capacity
to the filter tank size and the pool
volume specified in the specifications
below. The pump must have enough
power to be able to circulate all the
pool water 5 times a day - through the
MV-1030-1050-03-2019 . © All rights reserved Swim & Fun Scandinavia ApS
Specifications
Operation over pressure
Cord length including plug
Max. ambient temperature
Min. ambient temperature
Maximum pool size in litres
Pump power
Pumpe Flow Rate
Qmax l/min
Hmax m
Flow Rate Filtermateriale
Volumen Filtermateriale
El-installation
Pressure gauge
Pre-filter
Filter tank size mm
Power
El-installation
Hose connection mm
Pump type
filter material. As a general rule, the
cleaning capacity of the pump must
as a minimum be the pool water
volume divided by 5. The pump is
suitable for use in salt water.
Fitting and hose connection
The system can be mounted
directly on all pools with a regular
pump outlet, and is suitable for use
Classic 300
1050
Sand Filterballs
1.5 bar
1.5 metres
35 ºC
-4 ºC
22.500 liter
250 W
7.500 l/h
125
7,5
4.500 l/t 5.970 l/t
560 g
20 kg
Automatisk differential
switch (30 mA)
Yes
Yes
Ø 300
230V/50 Hz
Automatic differential
switch (30 mA)
Ø32/38
Self-priming
with standard hoses of Ø50 mm.
Filter material and hoses for pools
are not included.
Classic 400
1030
Sand Filterballs
1.5 bar
1.5 metres
35 ºC
-4 ºC
33.000 liter
450 W
8.000 l/h
142
9
6.000 l/t 6.970 l/t
840 g
30 kg
Automatisk differential
switch (30 mA)
Yes
Yes
Ø 400
230V/50 Hz
Automatic differential
switch (30 mA)
Ø32/38
Self-priming
