6 Parts overview and scope of delivery
3
4
14
B
Illustration 1: Parts overview for base station (top) and remote sensor (bottom)
1 SNOOZE/LIGHT button (snooze function and
temporary background lighting)
3 MODE button (time mode selection and set-
tings)
5 DOWN button (Value setting downwards, tem-
perature unit selection (°C/°F), pressure value
selection
7 CH button (channel selection)
9 Mounting hole (Base station)
20 / 76
1
zZ
z
8
5
6
7
21
2
A
10
11
15
16
C
22
23
2 Display
4 UP button (Value setting upwards)
6 ALARM button (Alarm setting)
8 WAVE button (Initiate data reception from the
wireless sensor)
10 Battery compartment (Base station)
