Tips for maintaining maximum battery life
1. Charge the
completely discharged.
Always stop tool operation and charge the
battery cartridge when you notice less tool
power.
2. Never recharge a fully charged
cartridge.
Overcharging shortens the battery service life.
3. Charge the battery cartridge with room
temperature at 10 ﾟ C - 40 ﾟ C (50 ﾟ F - 104 ﾟ F).
Let a hot battery cartridge cool down before
charging it.

FUNCTIONAL DESCRIPTION

CAUTION:
Always be sure that the tool is switched off and the
•
battery cartridge is removed before adjusting or
checking function on the tool.
Installing or removing battery cartridge
Fig.1
Always switch off the tool before insertion or
•
removal of the battery cartridge.
To remove the battery cartridge, withdraw it from
•
the tool while sliding the button on the front of the
cartridge.
To insert the battery cartridge, align the tongue on
•
the battery cartridge with the groove in the housing
and slip it into place. Always insert it all the way
until it locks in place with a little click. If you can see
the red part on the lower side of the button, it is not
locked completely. Insert it fully until the red part
cannot be seen. If not, it may accidentally fall out of
the tool, causing injury to you or someone around
you.
Do not use force when inserting the battery
•
cartridge. If the cartridge does not slide in easily, it
is not being inserted correctly.
Switch action
Fig.2
CAUTION:
Before inserting the battery cartridge into the tool,
•
always check to see that the switch trigger actuates
properly and returns to the "OFF" position when
released.
To prevent the switch trigger from accidentally pulled, the
lock-off button is provided.
To start the tool, depress the lock-off button from B side
and pull the switch trigger.
Release the switch trigger to stop. After use, always
press in the lock-off button from A side.
battery cartridge
Speed adjusting dial
before
Fig.3
The tool speed can be infinitely adjusted between 1.4
m/s and 2.7 m/s by turning the adjusting dial. Higher
speed is obtained when the dial is turned in the direction
of number 6; lower speed is obtained when it is turned in
battery
the direction of number 1.
Select the proper speed for the workpiece to be cut.
CAUTION:
The speed adjusting dial can be turned only as far
•
as 6 and back to 1. Do not force it past 6 or 1, or the
speed adjusting function may no longer work.
Lighting up the lamp
Fig.4
CAUTION:
Do not apply impact to the lamp, which may cause
•
damage or shorted service time to it.
Pull the switch trigger to light up the lamp. The lamp
keeps on lighting while the switch trigger is being pulled.
The lamp goes out 10 -15 seconds after releasing the
trigger.
NOTE:
Use a dry cloth to wipe the dirt off the lens of lamp.
•
Be careful not to scratch the lens of lamp, or it may
lower the illumination.
Do not use thinner or gasoline to clean the lamp.
•
Such solvents may damage it.
When the tool is overloaded during operation, the
•
lamp flickers.
When the remaining battery capacity becomes
•
small, the lamp flickers.
ASSEMBLY
CAUTION:
Always be sure that the tool is switched off and the
•
battery cartridge is removed before carrying out
any work on the tool.
Installing or removing the blade
CAUTION:
Oil on the blade can cause the blade to slip or come
•
off unexpectedly. Wipe off all excess oil with a cloth
before installing the blade.
Use caution when handling the blade so that you
•
are not cut by the sharp edge of the blade teeth.
Turn the blade tightening lever clockwise until it hits
against the protrusion on the frame.
Fig.5
Match the direction of the arrow on the blade to that of
the arrow on the wheels.
