Safety notes

Power
Before you connect the terminal power pack to an electrical outlet, check that the on/off power switch
on the terminal is off. If the terminal does not have an on/off switch, check that the power cable
connector is removed from the terminals´s power port. Or, when connecting the terminal to a power
pack, always connect the plug of the power pack to an electrical wall outlet first. Then connect the
power cable to the terminals´s power port. The power pack is rated as follows: Input Voltage 100 - 240
VAC 50/ 60 Hz (0,2 A max.) and output voltage 9V DC, 1,0 A.
Do not use the adapter in a high moisture enviroment. Never touch the adapter when your hands or
feet are wet.
Allow adequate ventilation around the adapter. Avoid locations with restricted airflow.
Connect the adapter to a proper source. The voltage and grounding requirements are found on the
product case and/ or packaging.
Do not use the adapter if the cord is damaged.
Do not attempt to service the adapter. There are no serviceable parts inside. Replace the unit if it is
damaged or exposed to excess moisture.
Disconnecting power
Disconnecting power during a transaction may cause transaction data files that are not yet stored in
terminal memory to be lost. Never remove the battery pack from the terminal if it is in the process of
performing a payment or other transaction („Please wait..."). If this message appears for a longer peri-
od of time, please contact your network provider.
Payment
The terminal is designed only for cashless payments using debit, credit, and customer cards (magnetic
stripe/ chip/ contactless) and must be used only for these cards.
Repair
Never try to open the terminal. In case of unauthorised opening, all safety-related data is deleted and
the device is out of order. Repairs may be performed by the manufacturer only.
The removal of or damage to type plates and seals attached to the device lead to the expiration of any
warranty claims.
Seite 18
Technische
Daten
Prozessor/ Speicher
Cortex-A9 Prozessor mit 1000 MHz/ 512 MB Flash und 512 MB SDRAM, erweiterbar mit Micro SD bis zu 82 GB
Tastatur
10 numerische Tasten, 5 zusätzliche Funktionstasten, hinterleuchtete Tastatur
Display
4" Farbdisplay, 480 x 800 Pixel (WVGA) , kapazitiver Touchscreen
Kommunikation/ Schnittstellen
WiFi (IEEE 802.11 a/b/g/n/ac bis 433.3Mbps), analog, LAN, RS232, USB (Host + OTG), BT
Externes Netzteil
Eingang: 100-240 VAC, 50 /60 Hz, Ausgang: 9V / 1,0 A
Kartenleser
- 3 Spur Magnetstreifenleser, bidirektional
- Chipkartenleser EMV L1 & L2
- Kontaktlos-Leser nach ISO 14443 A/B, MIFARE, FeliCa, NFC für MasterCard Kontaktlos, Visa Kontaktlos, girogo,
girocard kontaktlos, American Express Kontaktlos
Dimensionen (L x B x H)
181 x 83 x 72 mm, Gewicht 410 g
Umweltbedingungen
Betriebstemperatur: -10°C bis 50°C, Lagertemperatur: -20°C bis 70°C, 10%...93% Luftfeuchtigkeit, nicht konden-
sierend
Zulassungen
PCI-PTS 4.x, EMV, DK TA7.1, RoHS
Audio
Lautsprecher
Drucker
Integrierter Thermodrucker, grafikfähig, 30 Zeilen/Sekunde, Papierrollendurchmesser: 50mm
