Step 6
Fold the armrests again once the client has taken a seat in the chair
(See section 3.4. Armrests) .
Step 7
Notify the client about the processes you will be carrying out .
Step 8
Take the wheels off the brake when you wish to move the chair
(See section 3.1. wheel blocking).

3. Operation

3.1. Wheel blocking

• The brake can be applied on the Tango XL by pushing the
blue lip (1) on the wheel downwards (See figure 1) .
• In order to take the Tango XL off the brake, the same lip on
the wheel must be moved upwards by tapping the upper
side of the lip (2) (See figure 1) .

3.2. Directional / braked wheel

The Tango XL has a standard
design with a directional / braked
caster . This makes pushing along
greater distances easier because
the seat will drift less sideways .
The directional / braked caster
is fastened in front .
To block the wheel direction, push
down the black lip . N .B . Make sure
that the black lip 1 stand moves downwards (1) (See figure 2) to lock the direction .
When the black lip 2 moves downwards, the wheel will be blocked . In order to lock
the direction again, the same lip on the wheel must be moved upwards by tapping
on the upper side of the black lip (2) (See figure 2).
22 | Instructions for use | Tango XL Shower-toilet chair
2
1
Figure 2 Directional / braked wheel .
2
Figure 1 Swivel wheel .
1
