EN
CABLE TANGLED IN THE DRUM
This is almost always caused by using too much pressure when feeding the cable, or by feeding the cable while
running the machine in reverse. To untangle, rotate drum in opposite direction. This will usually get the cable
to lie in the drum properly
If cable has become badly tangled, which shouldn't happen when machine is used properly, it can be
straightened out by removing the distributor tube from the drum. To do this:
1. Loosen the four bolts that hold the front drum hub on the front of the drum.
2. Pull the front drum hub and distributor tube forward, then pull the tangled portion of the cable out of the
drum.
3. After the cable has been straightened out, slide the distributor tube and front drum hub back along the
cable until it can be repositioned and bolted to the front of the drum.
4. Then, push the excess cable back into the drum.
HOW TO INSTALL Ø 12.7 AND 9.5 MM CABLES ON THE DRUM
1. There is a connector inside the drum which receives the rear-end of the cables. Turn the drum until this
connector is at the bottom.
2. Position the cable distributor tube such that it is curved to wards the bottom.
3. Insert the cable into the drum until it is wound around it for almost an entire turn.
4. Reach inside the drum and connect the cable to the connector.
5. Remove the the drive belt and turn the reel clockwise with one hand whist feeding the cable into the drum
with the other.
HOW TO REMOVE THE DRUM FROM THE MACHINE
1. Remove the drive belt. You may relieve tension on the belt by applying pressure to the motor which is spring-
mounted.
2. Locate the holding latch behind the drum. Pull the drum forwards, whilst pulling on this latch to remove it
from the machine.
3. The drum can be replaced by repeating these procedure in reverse order.
HOW TO USE THE 291223 DRUM
The 291223 drum is for use with Ø 6.35 or 8 mm cables. These cables are fitted with a sink U-bend head that
can pass through most U-bend fittings.
To install the cable, fully open the jaws of the chuck such that the cable may pass freely.
Tighten the chuck when working on difficult obstructions or tight bends to avoid the cable becoming entangled
inside the drum.
Regularly clean and lubricate the chuck against rust.

CARE AND MAINTENANCE

IMPORTANT: Pull the mains plug before carrying out any work on the machine! Clean the machine at regular
intervals.
For your machine to function correctly, it is essential that all bearings and cables are lubricated with
VIRAX 290400 specific drain cleaning machine oil. It is especially important to lubricate all moving parts
when the machine is used in an environment where sand, dirt or other abrasive materials are present.
All other servicing, maintenance and repair work may only be carried out by VIRAX

WARRANTY

The VAL 80 pipe cleaner is guaranteed for 2 years, excluding parts subject to wear and tear.
Interventions or repairs by unauthorized workshops will cancel any warranty.
