Part Names

See Illustrations A.

Control Panel

The control panel (B) has the Power LED, Error LED, Charge LED, Battery LED,
Feed button, and Power button.
Control Panel (LEDs and Buttons)
Power LED (Blue)
Power LED
On
Off
Flashing
Error LED (Orange)
Printer Condition
Power On
Charge LED (Orange)
Printer Condition
Power On and
battery
installed
Battery LED (Blue)
Printer Condition
Power On
Power button
Press this button to turn the power on or off. To turn the power off, hold the
button for more than 2 seconds.
Feed button
Press this button to feed paper.
Installing and Charging Battery
Follow the steps below to install and charge the battery.
Note:
The battery can be charged only when the temperature is 0 ~ 40°C {32 ~ 104°F}.
Meanings
Power is on.
Power is off.
The printer is powering-off and powering-on.
Error LED
On Printer is offline (paper out, power-on initialization, roll
paper cover open, the remaining battery charge is at E
level).
Off Printer is in normal operation.
Flashing Printer is in error.
Charge
LED
On The battery is being charged.
Off The battery is fully charged.
Flashing There is abnormality in battery charging.
Battery Error Battery
LED charge status
LED
3 LEDs On Off Level H
2 LEDs On Off Level M
1 LED On Off Level L
1 LED Off Level S
flashing
3 LEDs Off On Level E
Meanings
Meanings
Meanings
You can continue printing, but
replacement or charge of the
battery is recommended.
Replace or charge the battery.
The printer goes offline and printing
is no longer possible.
TM-P80 User's Manual 5
