Home screen (temperature control)

Press on the Airzone icon once to deactivate the screensaver and go to home. Once
there, you will find the following functions:
Operating mode
Zone
Settings menu
Relative humidity
Sleep Mode
Home screen/Confirm
Operating modes: It displays the operating mode selected from the Master controller
(or from the Think thermostat if configured as Master). These are 5 available modes:
cooling, heating, dry, ventilation and stop (see settings menu on page 16).
Eco-Adapt saving function: It defines the level of energy efficiency set by the
Blueface.
Fan speed: It is an indicator of the fan speed of the AC unit. That speed is set from
settings menu (if it is a fancoil installation) or from the Master controller (see page
17).
Zone/Room temperature: It displays the zone where the thermostat is located.
Its name is defined from the Master Blueface thermostat. It displays the room
temperature of the zone.
Settings menu: The Sleep mode parameters can be always configured. If you have a
Master Think, you can change the mode. In addition, in fancoil installations, you can
also select the speed. (See page 16).
Set-point temperature: It displays the temperature set from the Think control bar
(see temperature control on page 15).
System speed
Eco-Adapt function
Control Bar
Set-point temperature
Time schedule
On/Off
