6. Battery and Charger

Specification

Battery type
Charging time
Battery specifications
Operating temperature
Charging voltage
6.1 Charging Process
1. Remove the charging socket cover found on the back of the scooter (see illustration).
2. Make sure the socket is dry and clean.
3. Plug in the charging cable. Make sure the plug is firmly seated in the socket.
4. When the indicator lights red, the battery is charging. When the battery is fully charged, the indicator lights green. Then stop the charging
process immediately.
6.2 Status Monitor
On the battery indicator you will find 4 levels. The battery is fully charged when all four lights are on. When the battery capacity is low, the
battery indicator flashes and makes a sound to indicate that charging is required soon. The wireless symbol blinks to indicate that the scooter
is connected to the app and settings can be adapted.
Note: If the e-scooter is not used 10 minutes after it has been switched on, the e-scooter will automatically switch off.
www.modster.at
Quantity
Litium-Ion
4-5 hours
36 V / 5,2 Ah (187 Wh)
Charge: 0-45° C
Discharge: -20-60° C
Storage: -20-45° C
AC100-240 V / 50-60 Hz
Notes
The operating temperature must not exceed or fall
below the temperature specified in this table.
The charging time highly depends on the environmental
conditions.
The loading capacity can change.
MODSTER R1
23
