(about 10/20 minutes) and insert the plug into the plug point once
again.
To use the fan heater, please follow the instructions below:
1) Insert the plug in the current socket
2) Turn the thermostat knob (C) clockwise to the position
corresponding to the desired temperature:
3) To switch the appliance on, turn the selector knob (B) to the
position corresponding to the desired function.
4) To turn the appliance off, rotate the knob to position "0" and take
the plug out of the socket.
Never leave the appliance connected to the socket if it is not in use,
especially for long periods.
Anti-frost device
Insert the plug into the power socket, turn the selector knob in pos. "
" and turn the thermostat knob to the anti-frost position (•): this
permits convector heater switching on when the ambient temperature
falls below +5°C.
type HF201 with 24 hour programmer (Fig.2)
The appliance has a switch, a thermostat and a 24 hour programmer,
light and anti-tipping switch, and function oscillation. The functions are
described in the previous paragraph; the programmer permits fan
heater "on" and "off" periods to be set during a 24 hour period, and of
repeating them systematically, day-after-day.
The programmer (D) is active when the button (E) on its side is aligned
with the " " symbol; if it is aligned with the "I" symbol, the
programmer is excluded.
If you wish the oscillation function, press the oscillation button "
and oscillation (rotation alternatively right and left).
To use the fan heater, act as described in points 1 and 2 of the previous
paragraph. Also:
a) Operating with the programmer excluded
a1)
Turn the switch to line up with position "
appliance comes on as does the luminous pilot light.
a2)
To switch off the appliance, turn the switch to pos. "0" (the pilot
light goes out) and remove the plug from the current socket.
b) Operating with the programmer (button pos
(button pos. "I").
" or "
.
