Location of controls

1 Control panel
2 Grill
3 Drive axle
4 Guide ring

Switches on the control panel

MICROWAVE
Microwave:
Select power setting of the microwave
GRILL (time controlled)
Grill:
For roasting and scalloping
Grill/Combi: Grill and microwave operate in turns
CONVECTION
Convection: Convection mode without microwave operation;
select a temperature.
COMBI. (temperature controlled)
Grill/Combi: Grill and microwave operate in turns
DEFROST Defrost by weight or time
STOP/CLEAR/CLOCK
Stop: Press once to stop cooking
Delete: Press twice to delete function
Clock: In combination with the turning knob for setting
the clock or cooking time
START/+30Sec./CONFIRM
• Starting the function
• Quick start of the microwave (always
+30 seconds at 100% power)
• Prolonging the cooking time by 30 seconds dur-
ing operation (except when defrosting by weight
or using auto functions)
• Confirming a setting
Locking
Press the STOP/CLEAR/CLOCK button and
START/+30Sec./CONFIRM button simultaneously
in order to lock the control panel (child-proof lock)
TIMER • WEIGHT • AUTO MENU
Turning knob for setting the clock, cooking time,
auto functions or weight settings

Symbols on the control panel

Symbol Meaning/function
Microwave
Defrosting
Grill
Microwave + grill

Information on grill and combi operation

• Use heat-resistant tableware only, as radiation heat develops during
grill and combi operation.
• When operating in grill mode only, you may also use metal or alumi-
num tableware, but not during combi or microwave operation.
• Only the grill is suitable for COMBI operation.
66
5 Turntable
6 Door latches
7 Viewing window
Symbol Meaning/function
Convection
Auto function
Power high/low
/
Child-proof lock activated
• Do not place anything on the top of the enclosure. It will become
hot. Always keep the ventilation slots unblocked.
• Use the grill to place the food closer to the heating element.

Suitable microwave tableware

• The most suitable material to be used in a microwave is transparent
and allows the microwave radiation to heat the food evenly.
• Round/oval bowls and plates are more suitable than square ones,
as the food might boil over at the corners.
• Microwave radiation cannot penetrate metal; therefore do not use
metal containers or plates.
CAUTION:
Do not use paper bowls made of recycled material, as these might
contain small amounts of metal which might cause flying sparks or fire.
The table below is intended to help you choose suitable tableware:
Material
Microwave Grill
Heat-resistant glass
yes
container
Non heat-resistant glass
no
container
Heat-resistant ceramic
yes
container/plate
Plastic containers suit-
yes
able for microwaves
Kitchen paper yes
Metal tray no
Grill no
Aluminum foil or alumi-
no
num foil containers
*) Combination of grill and microwave

Operation of the device

• A signal tone sounds when first turning the turning knob.
• Your selection by pressing buttons is confirmed by a signal tone.
If not, you did not press properly.
• If you set or pause a function and do not press the START/+30SEC./
CONFIRM button within 5 minutes, the setting will be canceled. The
current time will be displayed again.
• When the door is open, the lights in the oven are on. If the door is
not closed after 10 minutes, the lights turn off.
• When starting a program (except during pre-heating), the remaining
operating time will be displayed. The countdown runs.
• 5 signal tones will indicate the end of the program.

First-time use

• Remove all accessories from the cooking chamber, unpack them
and place the guide ring in the center.
• Place the glass plate on the drive axle in such a way that it will lock
into the dents of the drive shaft and rest evenly.
• Check the device for visible damage, especially in the area at and
around the door. It is imperative not to use the device in case of any
damage.
• In order to avoid interference with the operation of other devices, do
not place your device near other electronic devices.
• Remove protective sheets that might be attached to the enclosure.
• Connect the plug to a properly installed isolated ground receptacle.
Suitable for
Con-
Combination*
vection
yes yes yes
no no no
yes yes yes
no no no
no no no
yes yes no
yes yes yes
yes yes no
