Mac OS X users

When used with Mac OS X, the KONTROL49 will automatically use Mac OS X's built-
in MIDI driver.
For use with Mac OS X, the KONTROL49 requires Mac OS X 10.2 or later.
To set up the KONTROL49 for use with Mac OS X, follow the steps below.
1
Use a USB cable to connect the KONTROL49 to your computer.
2
Turn on the power of the KONTROL49.
3
Navigate to Macintosh HD > Application folder > Utility folder, and double-
click "Audio MIDI Settings".
4
Click the "MIDI Devices" tab, and verify that the KONTROL49 is displayed.
MIDI Driver installation and settings Driver

■ Mac OS X MIDI input and output ports

Using the Mac OS X MIDI drivers, the KONTROL49 provides a total of three MIDI
inputs and two MIDI outputs, as follows:
• One port each of MIDI input and output for external devices
• Two ports of MIDI input from the KONTROL49's own keyboard and controllers
• One port of MIDI output dedicated to KONTROL49 data dumps and Korg Native
mode
KONTROL49 MIDI OUT B
KONTROL49 MIDI IN
KONTROL49 dedicated port (CTRL)

■ Input Settings for Applications

The numbers assigned to these ports are a little different between the KONTROL49 front
panel and the Mac OS X MIDI drivers.
On the KONTROL49, you can set the different kinds of controllers - keyboard, pads,
sliders, encoders, and so on - to send data to either USB Port A or Port B (KONTROL49
Owner's Manual ☞p. 45 "[15] USB-MIDI Port setting").
In the Mac OS X MIDI drivers, these same two ports correspond to Port 2 and Port 3,
as shown below:
KONTROL49
(MIDI IN) MIDI IN
Input (Port A) PORT A
(Port B) PORT B
(MIDI OUT Port B) MIDI OUT B
Output
(Dedicated Port) CTRL
KONTROL49 Port B (PORT B)
KONTROL49 Port A (PORT A)
Names Displayed by Application
(MIDI input settings:) Port 1
(MIDI input settings:) Port 2
(MIDI input settings:) Port 3
(MIDI output settings:) Port 1
(MIDI output settings:) Port 2
9
