English
Display (example: pH measurement)
3
2
AutoCal TEC
1
HOLD AR
Info
Jack field /connections
Initial
commissioning
6
01.07.2011
USB output
08:00
1
1 Insert the supplied batteries.
Make sure that the poles are in the correct position.
2 Connect the power pack if necessary.
3 Switch on the meter with the <On/Off> key.
Caution
Follow the safety instructions of the used sensors.
The operating manuals of the sensors are available on the supplied CD and on
the Internet under www.WTW.com.
1
4
2
3
4
5
5
6
6
7
7
1
2
3
4
5
4
2 3
Status information
Measured value (with unit)
Measured parameter
Continuous measurement control
(CMC function)
Sensor symbol
(calibration evaluation)
Measured temperature (with unit)
Softkeys and date/time
Digital sensors
(pH, conductivity, D.O.)
USB B interface (device)
USB A interface (host)
Connection for line adaptor
Service interface
ba77151y01
Lab 875
10/2015
