Specifications

CPU
Chipset
Memory
Expansion Slots
Onboard
Graphics
Storage
Support AMD Ryzen™ 1st and 2nd Generation/ Ryzen™ with
®
Radeon™ Vega Graphics Processors for Socket AM4
AMD B450 chipset
®
y 2x DDR4 memory slots, support up to 32GB
ƒ Supports DDR4 1866/ 2133/ 2400/ 2667 MHz by JEDEC,
and 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz by
A-XMP OC mode*
y Dual channel memory architecture
y Supports ECC UDIMM memory (non-ECC mode)
y Support non-ECC UDIMM memory
* Please refer www.msi.com for more information on
compatible memory.
y 1x PCIe 3.0 x16 slot
ƒ Supports x16 speed with AMD
Generation processors
ƒ Supports x8 speed with AMD
Vega Graphics processors
y 2x PCIe 2.0 x1 slots
y 1x VGA port, supports a maximum resolution of
2048x1280@60Hz, 1920x1200@60Hz*
y 1x DVI-D port, supports a maximum resolution of
1920x1200@60Hz*
y 1x HDMI 1.4 port, supporting a maximum resolution of
4096x2160@24Hz*
* Only support when using AMD
Graphics Processors
* Maximum shared memory of 2048 MB
AMD B450 Chipset
®
y 4x SATA 6Gb/s ports
ƒ Supports RAID 0, RAID1 and RAID 10
y 1x M.2 slot (Key M)
ƒ Supports PCIe 3.0 x4 and SATA 6Gb/s 2242/ 2260 /2280
storage devices
Continued on next page
Ryzen™ 1st and 2nd
®
Ryzen™ with Radeon
®
Ryzen™ with Radeon Vega
®
3
