All measurements are given including a 45 cm 2 point spreader bar, except dimensions marked with *.
Invacare® reserves the right to change the measurements without warning.
** CSP: Central Suspension Point
1: Highest position, 2: Maximum reach position, 3: Lowest position

11. Symbols

The patient is not separated from the ground and the chassis:
Direct current:
Alternating current
Double insulated:
X kg max. load (SWL) = (Patient + sling + spreader bar).
X = 150 kg (Birdie Compact)
TM
X = 170 kg (Birdie
TM
The product should be reused where possible:
Refer to user's manual:
and Birdie Plus )
TM
