If the DHCP server is available, you can check the checkbox of DHCP to automatically obtain an IP
address and other network settings from that server.
4. After having configured the general settings, click the Apply button to save the settings.
5.7

Adding Cameras

Purpose:
Before you can get live video or record the video files, you should add the analogue and / or HD-TVI and / or up
to 2 network cameras to the connection list of the device.
Each two video channels are grouped in sequence, e.g. CH01 and CH02, CH03 and CH04, .... And each two
channels in the same group must be connected with the same type of video source selected on GUI. For
example, when the TVI / CVBS signal mode is selected, then either TVI or CVBS signal input can be connected
to the channels in the same group; and when the AHD signal mode is selected, only the AHD signal input can
be connected. The above information is for reference only. Please refer to the specific configuration of the
device (camera).
IP cameras are recommended to be used out of the product range of Eventys IPC – these cameras will be
detected automatically. 3
installation by the operator.
5.8

Live View

Icons are provided on screen in Live View mode to indicate camera status. These icons include:
Live View Icons
In the live view mode, there are icons at the upper-right corner of the screen for each channel, showing the
status of the record and alarm in the channel for quick reference.
Alarm (video loss, tampering, motion detection, VCA or sensor alarm)
Record (manual record, continuous record, motion detection, VCA or alarm triggered record)
Alarm and Record
Event/Exception (event and exception information, appears at the lower-left corner of the screen.)
© Vanderbilt 2017
rd
party IP camera can be used based on ONVIF protocol, but requires manual
Menu Operation
21
