24128

IMPorTanT feaTures

Tide Breaker Speedboat:
• Sturdy plastic hull
• With aligning function
• Safety system to prevent inadvertent
start-up of the motor

Safety instructions:

• This model is suitable for persons who
are at least 15 years of age. Supervision
by a parent or legal guardian is required
when operating the vehicle.
• Please keep this operating manual to
hand at all times. If you pass on the
model to anyone else, you should also
give them this manual.
• This model should only be operated in
accordance with the instructions for use
in this operating manual.
• The model must not be operated in salt
water. Using the boat in flowing water
is not recommended as it may drift
away in the event of a possible
malfunction.
• Switch off the remote control and the
boat's electronics when they are not in
use. Always switch on the remote
control before the model. When
switching off, always switch off the
model before the remote control.
• Remove the batteries from the remote
control and the model when they are
not in use.
• Monitor the model at all times in order
to avoid losing control of it.
• We recommend alkali manganese
batteries or rechargeable batteries for
the remote control and the model. Do
not use batteries with different states
of charge.
• As soon as the remote control no
longer functions reliably, new batteries
should be inserted. Should it still
continue to function unreliably, please
14
remote control:
• 2-channel GHz remote control
• Special charger for Li-ion batteries
return the model and remote control
for inspection.
• A model boat may remain stationary
on the water if it malfunctions or if
the batteries run down. Never
endanger yourself or others when
salvaging the model! Never swim
after a malfunctioning RC boat.
• The model has been constructed in a
way that makes it extremely difficult
for water to enter. However, it cannot
be guaranteed to be 100% watertight.
Should water enter the boat, open
the hatch, remove the batteries and
leave the model to dry completely
before using it again. If water has
penetrated into the remote control
components, send the controller in
for inspection and repair.
• Never steer the model whilst on
water. Always remain on dry land
when operating the boat!
• Due to the speed and size of this
boat, there is a significant risk of
injury to people and property in the
event of a collision. Never operate
the model in the presence of
swimmers and avoid places where
there is a risk of collision with people,
animals and other objects!
• The model is radio-controlled.
Accordingly, there may be inter-
ference from other radio transmitters,
radio systems or other electrical
systems.
• Never touch the propeller while the
motor is running. Keep your hands,
face, hair and loose clothing away
from the propeller. Otherwise
there is the risk of injury.
• Immediately release the speed
controller after a collision in order
to stop the boat!
• Some parts of the boat have sharp
edges and the electric motor can
become hot during operation.
Therefore always exercise caution
when handling the boat.
Maintenance and care:
• Please only use a clean cloth to
wipe off the boat.
• Protect the boat and batteries from
direct sunlight and/or direct heat.
The boat is equipped with a
rechargeable Li-ion battery.
Please observe the following
safety instructions
• Never throw Li-ion batteries into a
fire or store in hot places.
• Only the supplied Li-ion charger
may be used to charge this Li-ion
battery. The use of a different
charger may lead to the perma-
nent damage of the battery and
neighbouring parts, as well as
physical injury!
• Observe the instructions for the
charging process!
• Always ensure that the charging
process takes place on a fireproof
surface in a fire-resistant environ-
ment.
• Make sure that no water or other
liquids come into contact with the
charger!
• Do not leave the battery unsuper-
vised during the charging and
discharging process.
• The contacts may never be
disconnected or short-circuited.
• Never disassemble or alter the
battery contacts. Do not damage
or puncture the battery cells.
There is a risk of explosion!
• The battery must be kept out of
reach of children.
• The charger for the Li-ion battery is
specially designed for the charging
of the boat battery. The charger
may only be used to charge the
boat battery, not other batteries.
Safety instructions:
• The product may never be structur-
ally modified, otherwise it can be
damaged or pose a danger.
• Always switch off the boat and the
remote control after use.
Battery requirement for the boat:
Rated voltage: DC 7.4 V
Batteries: 1 x 7.4 V rechargeable
Li-ion battery (supplied)
Capacity: 1500 mAh
Charger:
Input: 240 V; 50/60 Hz;
Output: 7.4 V ===; 350 mA
Battery requirement
for the remote control:
Power supply: ===
DC 9 V batteries: 6 x 1.5 V "AA"
(not supplied)
1 BoaT
1A Water drain 1F Inlet for the
opening water cooling
of the motor
1B Canopy closure
1G Four locks for
1C Water contact for
the lower cabin
the protective
cover
circuit, also on
the underside of 1H Motor
the boat
1I Motor cooling
1D Rudder
1J Battery com-
1E Propeller partment
