INSTRUCTION MANUAL
use the correct type of bit for the job.
Secure small items in a vice or similar. Never hold
the item in your hand!
Check for concealed power cables, pipes etc in the
items or surface you are going to drill.
Place a piece of scrap wood under the item if
possible. Avoid the drill damaging objects under
or behind the item, e.g. when drilling in walls.
Always maintain a firm grip on both handles when
using the machine.
Avoid blocking the ventilation slots with your
hands.
The drill must not be in contact with anything
when starting it.
Always use ear protectors when using the hammer
drill function.
Drilling certain substances can cause harmful dust.
Always wear a mask.
The drill must be totally stopped before switching
between drilling and hammer drilling, changing
direction or drill speed.
Never put the drill down if the chuck is still
rotating (e.g. if the lock button is still depressed).
Wait until the chuck has stopped completely
before putting the drill down, and pull the plug
out of the socket if it is not to be used further.
Avoid touching the drill bit after use. It may be
very hot.
Always secure the chuck key in its holder when not
in use.
Preparation and adjustment
Turning the support handle
The support handle (7) can be rotated around the
drill chuck to a position to suit - e.g. vertically
under the machine, horizontal out to either side.
Loosen the handle by turning it anti-clockwise.
Move to desired position and tighten by turning in
the opposite direction.
Changing bits
Insert the chuck key in one of the three holes on
ENGLISH
the side of the chuck (8), turn to open.
Insert the desired bit in the chuck and turn the
chuck key the opposite way until the chuck has a
firm grip on the bit.
Check that the bit is in the centre of the chuck
and is secure.
Adjustment of depth guide
To drill several holes to the same depth, use the
depth guide (9). Loosen the depth adjustment
screw (10), set the guide to the required depth
and tighten the screw again.
Drill/hammer drill selection
Select drill or impact drill using the toggle switch
(6). Push the switch to the right for impact drill
and to the left for ordinary drilling. Select impact
drill for masonry, stone and cement. Select
standard drill for wood, metals, marble, tiles, lime
cement or man-made materials.
Selecting direction
Select direction (left (L) or right (R)) using the
direction selector switch (5). The impact drill
function can only be used when the switch is
pushed to the right.
Setting drill speed
Drill speed is infinitely variable depending on how
far the on/off switch (2) is depressed. Maximum
speed can be set by turning the speed adjustment
button (3). Turning it towards H increases speed,
turning it towards L decreases speed.
Use
Fit a suitable bit for the job and adjust the depth
guide again if required.
Select the appropriate speed on the speed
adjustment button, select drill or hammer drill
and check that the direction setting is correct.
Start the drill by pressing the on/off button.
For continuous use over extended periods, the on/
off button can be held down by pressing the lock
button (1) in at the same time the on/off button is
depressed. The lock button can be released by
pressing the on/off button in as far as it will go.
16
