Li-Ion Digial-Photo-Charger Combi I
A
Loading a accu onto the Video Accu Charger
Slide the Accu onto the platform as indicated (picture A). Do not force the Accu onto
the platform. Use the adapter tray as indicated (picture B). To remove the adapter tray
simply pull back on the release tab and lift the tray up from the charger (picture).
Charging Mode
When the Accu is attached onto the charger platform the Accu status indicator will
light up (green LED) and blink as long as the Accu is being charged. If the Accu is
fully charged, the indicator will stop blinking and light up permanently. Then the Accu
pack can be removed from the charger. It is recommended to still leave the Accu
pack on the charger for approx. 30 minutes to "top-off" the battery.
Safety precautions and maintenance
DO NOT use the Accu charger inside a drawer, closed cabinet or cover with a cloth.
The heat from charging may damage the charger and the battery pack. During use
the charger will become slightly warm.
DO NOT attempt to open the charger or remove service parts inside. Doing so will
void your warranty. DO NOT allow moisture of any kind to come into contact with the
charger; never immerse the charger in water for any reason.
DO NOT install the charger in areas that may expose it to extreme temperatures.
Avoid placing the charger in direct sunlight, such as on a dashboard. High temperatu-
res may warp or melt plastics. DO NOT drop the charger. Serve jolts may cause per-
manent damage and are not covered by the warranty. DO NOT plug the 12V car cord
into the cigarette light socket of truck vehicles since it will cause permanent damage
to the charger.
14:58 Uhr Seite 6
B
6
l l
Li-Ion Digial-Photo-Charger Combi I
Technical Specifications
Input: 12 VDC
Charging Current: 800mA constant current mode
Charging Mode: constant current mode with charging current
termination (4.2V for 3.6V/3.7V Accu, 8.4V for 7.2V/7,4V Accu)

Troubleshooting

Problem Remedy
No power status LED (red LED) • Make sure the AC/DC power adapter
is plugged into a suitable power outlet.
• Check power cord.
No Accu status LED • Re-install Accu.
(green LED) when • Defective Accu.
Accu is installed
Power and Accu status LED • Disconnect outlet of power from charger
of the adapter both blinking and re-connect it to charger.
• Defective Accu.
