Technical Specifications - Beyerdynamic UNITE TP Kurzanleitung

26
receiver should light up green and the display
should show the channel name of the transmitter.
8. If you want to clear the stored pairing information,
hold down the "Copy/Reset button
five seconds. The status indicator
permanently green.

6. Technical specifications

DECT RF frequency range . . . . . 1880 - 1930 MHz,
DECT transmission power . . . . . up to 250 mW (peak),
DECT operating range. . . . . . . . . up to 300 m outside
Audio bandwidth
Low quality (SD). . . . . . . . . . . . . . 200 Hz - 7 kHz (-3 dB)
High quality (HD). . . . . . . . . . . . . 100 Hz - 14 kHz (-3 dB)
Operating mode . . . . . . . . . . . . . . Broadcast and/or
Encryption . . . . . . . . . . . . . . . . . . . . AES-256 bit encryption
Headphone/headset/
induction loop connector . . . . . 4-pin mini jack, 3.5 mm,
Unite TP – Bodypack Transmitter
for more than
will then remain
depending on the country
depending on the country
(line of sight);
the actual operating
range depends upon the
RF output settings, the
surroundings, the signal
absorption, signal
reflection and signal
interference
full-duplex on all routes
CTIA Standard
