RECHNER SENSORS KFI-5-1...ETW Serie Bedienungsanleitung Seite 29

Reset KFI-5-2...ETW (2 Switching Points)
• Connect the grey wire (ETW) with the supply voltage (+) and release the adjustment connection (ETW)
within >13 and <18 seconds. The LED switches off for 1.5 seconds.
• A1 and A2 = OFF, reset successful
ETW
H
L
LED
ON
OFF
A1 + A2
ON
OFF
The probe can be reset at any time.
T 3s
0
T 3s
0
T
3s
0
8s 13s
13s
8s
8s 13s
Reset
18s
[1,5 s]
18s
18s
t
t
t
