How the System Works

The PetSafe In-Ground Cat Fence
6 months old. The system works by producing a radio signal from the Fence Transmitter through up to 1200 m (4000 ft) of
Boundary Wire. The Boundary Wire is buried or attached to a fi xed object to enclose the Pet Area. You temporarily defi ne
this Pet Area with Boundary Flags for a visual aid in training your cat. Your cat wears a Receiver Collar with Contact Points
that touch his neck and, once trained, is allowed to roam freely in the Pet Area. When your cat reaches the Warning Zone, the
Receiver Collar gives a warning beep. If your cat continues into the Static Correction Zone, a safe Static Correction will be
delivered through the Contact Points to get his attention until he returns to the Pet Area.
Key Definitions
Fence Transmitter: Transmits the radio signal through the Boundary Wire.
Pet Area: Area within the Warning Zone where your cat can roam freely.
Warning Zone: Outer edge of the Pet Area where your cat's Receiver Collar begins to beep, warning him not to go into the
Static Correction Zone.
Static Correction Zone: Zone beyond the Warning Zone where your cat's Receiver Collar will emit a Static Correction,
signaling him to return to the Pet Area.
Boundary Width: Combination of the Warning Zone and the Static Correction Zone.
Receiver Collar: Receives the radio signal from the Boundary Wire.
Receiver Indicator Light: Indicates the level of Correction at which the Receiver Collar is set. This light also serves as a
low battery indicator.
Contact Points: Deliver the safe Static Correction when your cat moves into the Static Correction Zone.
Magnet Key Dot: Adjusts the Static Correction Level.
Power Jack: Where the Power Adapter plugs into the Fence Transmitter. The Fence Transmitter is powered by a standard
220-240 volt outlet.
Boundary Control Switch: Adjust according to the length of Boundary Wire used.
Boundary Wire Terminals: Where the Boundary Wire connects to the Fence Transmitter in order to complete a
continuous loop.
Loop Indicator Light: Indicates that the Boundary Wire makes a complete loop, enabling the signal to be transmitted.
Boundary Width C ontrol: Adjusts the width of the Warning and Static Correction Zones. Note: Adjusting the knob does not
change the level of Static Correction on the Collar.
Fence
Transmitter
Pet Area
Static Correction
Zone
Warning
Zone
4
Downloaded from www.Manualslib.com
™
has been proven safe, comfortable, and effective for all cats over 2.7 kg (6 lb) and at least
Receiver Collar
Static Correction
Zone
Warning
Zone
Contact
Points
Boundary
Width
Washers
manuals search engine
(Top)
Receiver
Indicator
Light
Battery Lid
(Bottom)
Magnet
Key Dot
www.petsafe.net
Fence Transmitter
}
Loop Indicator Light
Power Power Light
Jack
Boundary Width
Control
Boundary
Control
Switch
Boundary Wire
Terminals
