GRAUPNER SOARMASTER COMPACT Anleitung Seite 31
Servo extension leads required (in the fuselage)
Order No. 3935.105
Order No. 3935.18
Order No. 3935.18
and
Order No. 3935.75
Order No. 3935.18
Order No. 3935.11
Order No. 98516.1
Order No. 98516
Electric motor and accessories
Motor
Order No.
COMPACT 490
16 V
6523
INLINE 700
6540
Radio control system for the SOARMASTER COMPACT
We suggest the following items as the minimum equipment for this model:
For the electric glider version
1
mc-19 35 MHz radio control system or better, e.g.
2
DS 281 servo
2
DS 3210 servo
2
C 3241 servo
1
DS 19 receiver
1
8RC 300 MH transmitter battery
1
4NH-1700 RX receiver battery
We deliberately recommend rechargeable batteries for the receiver and transmitter, as they provide
the broadest margin of safety.
Please refer to the main FS catalogue for details of battery chargers.
The building instructions
The basic rule is to trial-fit parts before reaching for the glue, and trim them where necessary. Some
components are deliberately over-sized to allow for this. We recommend that you sort out the parts
into groups relating to the fuselage, wing panels, tail panels etc.
Cover your work surface with soft foam to avoid damaging the finished surfaces.
You may wish to deviate from the sequence of assembly described in these instructions; you do this at
your own discretion and risk.
Refer to the building instructions and stage photos constantly while you are completing the
model.
Note that balsa knives, pins and wire ends are sharp and pointed, and can easily cause injury.
for rudder and elevator
for speed controller
for ailerons
for wing centre section
for camber-changing flaps
for connecting extension
leads to receiver
Folding ferrite ring for
aileron and flap servo leads
Folding ferrite ring for
rudder and elevator
Propeller
Spinner
Order No.
Order
No.
45 x 25 cm
9500.4
1336.45.2
5
5
40 x 25 cm
9500.4
1336.40.2
5
5
2 leads
1 lead
2 leads
2 leads
2 leads
4 leads
1
1
Flight battery
Order No.
SANYO 12N-2400
RC
14.4 V / 2.3 Ah
2476 or
LiPo 3 / 3200 11.1
V
7650.3
SANYO 12N-2400
RC
14.4 V / 2.3 Ah
2476 or
LiPo 3 / 3200 11.1
V
7650.3
6
Speed
controller
Order No.
COMPACT
CONTROL
50
2885 or
Genius 40
2896
COMPACT
CONTROL
50
2885 or
Genius 40
2896
Order No. 4821
Order No. 5148
Order No. 5200
Order No. 3900
Order No. 3221
Order No. 3239
Order No. 7552
