CLX.PAYPEN FUNCTioNS

CLX.PAYPEN FUNCTioNS (VALiD FoR WiNDoWS oNLY)

you can access all the CLX.PayPen functions from the taskbar icon. Click on the CLX.PayPen
taskbar icon with the right mouse button to display the menu.
CLX.PayPen
Taskbar icon
generaL
cLX.PayPen can alternate between the following functions:
• Text and digits – Scanning of text and digits
• Numerics – Scanning numbers only
• Banking – Scanning of payslips
• Barcodes – Scanning of barcodes
the icon in the toolbar indicates the active mode:
Text and digits Numerics
Switching between the individual modes:
Click on the CLX.PayPen icon in the toolbar with the left mouse button. The CLX.PayPen
menu will be opened. Now click on the desired mode. in the CLX.PayPen menu, the dot
signalises which of the four modi is activated.
the following conditions must be met in order to be able to use cLX.PayPen:
• The CLX.PayPen must be connected to your PC or notebook.
• The CLX.PayPen software must be started.
The CLX.PayPen must be in the correct mode. The CLX.PayPen symbol below in the right
hand side of the task bar shows which mode is currently active.
Example: Banking mode
50
CLX.PayPen
Taskbar menu
Banking Barcodes

hoW To READ WiTh YoUR CLX.PAYPEN

BanKing – PaySLiPS
1. hold the CLX.PayPen like a regular pen. To record a payment, scan only the code line on
the lower edge of the payment slip (see figure).
2. Place the tip of the CLX.PayPen in front of the first digit in the code line. The CLX.PayPen
starts the reading process as soon as you press the automatic trigger against the surface.
3. Move the scanner swiftly and as precisely as possible over the code line, applying light
pressure as you do so. if you are left-handed, you can also scan from right to left.
4. once you have successfully recorded the data, the payslip appears in your payment or
accounting software (e.g. PayMaker) on the screen completely filled out.
note: The code line you scanned is checked to ensure that it is correct. if the code line
is found to be complete and free of errors, it is written in the correct format to the cursor
position of your payment transaction or accounting software. Thanks to the built-in digit
check, only correctly scanned data is transferred to your software.
The code line contains the relevant data such as amount, reference number and account
number.
hoW To READ WiTh YoUR CLX.PAYPEN
Codeline
51
