TermaCook
Instructions for assembly
Worktop 600 mm
40 40
max.430
max.430
max.300
140
255
Worktop ≥ 680 mm
>120
max. 430
max. 430
140
255
Outgoing air outlet on left
Outgoing air outlet on right
40
max. 430
Outgoing air outlet on left
Outgoing air outlet on right
Bodenausschnitt 800
Cut-out in the base 800
NW150
800
Option of outgoing air on the left or right:
depending on the installation situation, the outgo-
ing air outlet may be installed on the left or right.
Please observe the dimensions on the right/left for
optimal planning.
Cut-out in the base 800
NW150
800
Option of outgoing air on the left or right:
depending on the installation situation, the outgo-
ing air outlet may be installed on the left or right.
Please observe the dimensions on the right/left for
optimal planning.
GB
≥335
165 ≥170
NW150
≥335
165 ≥170
NW150
41
