18. Troubleshooting chart

Fault Probable cause
Short-circuit - Motor or cable short-circuit
- Wrong power supply connection
- Wrong connection of the cable shield
Frequency - Ambient temperature too high
converter - One or more frequency converter fans
overheating faulty
Low supply voltage - Supply voltage lower than 330V
High supply voltage - Supply voltage higher than 520V
Overcurrent - Step up/down ramp too high
- Improper connection of the motor
- Wrong motor settings
Electronic card Electronic card overheating
overheating
Dry-run The pump is running with no water
1) For electrical reparation, disconnect the supply voltage from the frequency converter. Refer to the safety
regulation described in section 4.
19. Filters for the reduction of irradiated noise and electromagnetic noise emissions
I-MAT Inom (A)
0.1 - 2
I-MAT 5.2TT-A 2 - 4
4 – 5.2
5.3 - 6
6 - 8
I-MAT 11.2TT-B
8 - 10
10 – 11.2
11.3 - 12
12 - 16
I-MAT 25.8TT-C 16 - 20
20 - 24
24 - 30
30 – 37
37 - 48
I-MAT 65,4TT-D
48 – 60
60 – 65,4
65,4 – 75
75 – 90
I-MAT 119TT-E
90 – 115
> 115
I-MAT_Ed3 - Operating Instructions
Possible solution
- Check motor connections
- Check power supply voltage
- Check the condition of installation (see section 3.1)
- Change the defective fans
- Check the supply line
- Check the supply line
- Increase the time of the ramps (see section 16.2)
- Check the parameters of the motor (see section 16.1)
- Check the frequency converter settings and motor data (see
section 16.1)
- Check the condition of installation (see section 3.1)
- Reduce the carrier frequency
- Check the suction and delivery manifold and the priming
conditions
- Check the performances curves of the pump
Filter Sinusoidal filter
CNW 933/6
CNW 854/8
CNW 933/8
CNW 854/10 CNW 933/10
CNW 854/12 CNW 933/12
CNW 854/16 CNW 933/16
CNW 933/20
CNW 854/24
CNW 933/24
CNW 854/30 CNW 933/30
CNW 854/37 CNW 933/37
CNW 854/48 CNW 933/48
CNW 854/60 CNW 933/60
CNW 854/75 CNW 933/75
CNW 854/75 CNW 933/75
CNW 854/90 CNW 933/90
CNW 854/115 CNW 933/115
CNW 854/150 CNW 933/200
Maximum length
No length limit
