Davey Water Products recommends that all installations are fitted with
earth leakage or residual current protection devices.
CAUTION:
In the interest of safety, we advise that all brands and types of pool pumps
must be installed in accordance with AS3000 wiring rules or equivalent
In accordance with AS 3350.2.41 we are obliged to inform you that this pump
is not to be used by children or infirm persons and must not be used as a
toy by children.
If the pump and filter are located below pool water level, it is necessary to
fit isolating valves in the pipe between the pump and the skimmer box and
in the return pipe from the filter to the pool.
The fittings on this product are constructed of ABS. Some PVC jointing
compounds are incompatible with ABS. Check compound suitability before use.
Warning! Ensure that an electrical isolation switch is located with easy
access so that the pump can be switched off in an emergency.
Power Connection - Three Phase
Three phase models are designed for connection to a nominal 400V power supply, but must be wired with a
contactor with 'quick-trip' (or M10 rated) overloads set a 4.3 amps.
Davey recommend the use of overloads which also have the ability to detect "single phasing" or "dropped
phase" conditions in the power supply.
NOTE: Three phase motors do not have capacitors fitted in the capacitor cover.
1. Remove bolt and washer (1) from the rear of the pump using a ½" socket and remove the rear pump
cover (2).
2. Carefully pull out the wiring from within the capacitor housing which is located on top of the outer cover (3)
3. Locate the white terminal block and unscrew the wiring from the test power lead side of the block
4. Three phase Silensor pumps have been designed to allow for connection one side of the capacitor cover
with a 3/4" access hole (4). Unscrew the power lead cable grommet from the side of the capacitor housing
and remove the short test power lead from the pump
5. Thread the replacement operational power lead through the lead hole on the left hand side of the
capacitor housing. Fasten the power lead into place with the compression cable grommet.
6. Wire the operational power lead into the terminal block, same as discarded test lead
7. Check that the three phase wiring is correct by connecting the lead to power and ensure that the motor
shaft is turning correctly in a clockwise direction. This should be done by switching the pump on for one
second or less, before the pump is primed. A directional arrow can be found on the rear end shield (5).
IMPORTANT NOTE:- THREE PHASE MODELS ONLY
BEFORE FINALISING WIRING CONNECTIONS AND BEFORE PRIMING PUMP,
CHECK THAT THE MOTOR ROTATES IN DIRECTION OF ARROW (CLOCKWISE
WHEN THE SHAFT IS VIEWED FROM THE WIRING CONNECTION END).
TO ALTER ROTATION, CHANGE ANY TWO POWER LEADS AT MOTOR
TERMINALS.
3
