Prior to using this pump you must ensure that:
• The pump is installed in a safe and dry environment
• The pump enclosure has adequate drainage in the event of leakage
• Any transport plugs are removed
• The pipe-work is correctly sealed and supported
• The pump is primed correctly
• The power supply is correctly connected
• All steps have been taken for safe operation
Appropriate details for all of these items are contained in the following Installation and Operating Instructions.
Read these in their entirety before switching on this pump. If you are uncertain as to any of these Installation
and Operating Instructions please contact your Davey dealer or the appropriate Davey office as listed on the
back of this document.
Your Davey Silensor ®
Congratulations on your purchase of a quality product from the Davey range of Pool and Spa Equipment.
They should not be used for any other purpose without first consulting your Davey Dealer or the Davey
Customer Service Centre.
Davey design and build its own electric motors especially for its pumps. The matched motor and "pumping
end" are designed to provide the quietest operation while delivering maximum water flow.
Davey's innovative water cooled motor incorporates manual overload protection with a built-in automatic
thermostat designed to protect the motor from overheating. This protection will also prevent 'dry run'
damage.
Every Davey Silensor® is thoroughly tested against a number of pressure, voltage, current and mechanical
performance parameters. Davey`s advanced pump manufacturing technology provides reliable and efficient
pumping performance that lasts and lasts.
Location
The pump should be located as close to the water as practicable and mounted on a firm base in a well
drained position, high enough to prevent any flooding. It is the installer's/owners responsibility to locate the
pump such that the nameplate can be easily read and it can readily accessed for service.
Weather Protection
It is recommended that the pump is protected from the weather.
Power Connections
NOTE: The pump must be supplied through a residual current device
(RCD) having a rated residual operating current not exceeding 30mA.
Power Connection - Single Phase
NOTE:
1. Ensure motor is connected to power supply specified on nameplate.
2. Avoid long extension leads as they can cause substantial voltage drop
and operating problems.
3. Although the Davey electric motor is specifically engineered to perform
on a range of power supply voltages, malfunctions or failure caused by
adverse voltage supply conditions are not covered under guarantee.
Power connections and wiring must be carried out by an Authorised
Electrician.
Davey Silensors are suitable for connection to a nominal 220/240 volt 50Hz power supply. The pump
®
is supplied with a 3 metre lead which must be connected by an electrician. Always ensure that the earth
conductor included is connected to a good earth. Extension cords are unsafe around pools - and should be
avoided. If the supply cord of this product is damaged it must be replaced by the dealer or manufacturer.
All single phase Silensor
overload on motor cause thermal to open circuit and switch motor off, it will not re-set and switch motor on
until power to the motor has been turned off and then turned back on.
® models have manual re-set thermal overload protection built in, i.e. should
