- Mount the ESC low-vibration and shockproof in your model. Be sure there is always enough
cooling for motor, ESC and battery. Zip ties are not a good method for mounting since parts on
the PCB can be damaged by pulling the ties to hard.
- Connect the servo plug of the ESC to the respective port of your receiver.
- The motor is connected to the three cables using gold plated plugs or soldered directly. Polarity
makes no technical difference. In case of rotating in the wrong direction you can simply
exchange two plugs of the motor or program reverse direction. Caution: Luster terminals etc.
are no suitable connections.
- We recommend gold plated plugs only which have to be soldered correctly to the cables. Cables
to the battery should be as short as possible, maximum 15 cm long. Always pay attention for
correct polarity.
- Wrong polarity causes destruction of the ESC. Never connect the battery to the motor
connection cables, this will also destroy the ESC.
- Motor cables should be as short as possible but this length is not that critical. Longer cables
should be twisted. In any case the receiver unit should be mounted as far away as possible from
current carrying cables.
- Use this ESC with suitable batteries only. Never use a power supply unit.
- Always ensure perfect functionality of the receiving unit in your model by doing a range test.
Also do this test with running motor!
- The safety features of the ESC only can be useful in "normal" operation. A shortcut of the
winding or the wires for example the ESC also can be destroyed. Therefor check all cables an
connectors every time before use.
- Voltage reversal will destroy the ESC. This can be verified and there will be no warranty on.

5. Parametrierung mittels Fernsteuerung / Programming with transmitter

Die X-Pro Drehzahlsteller sind im Auslieferungszustand bereits optimal für Hacker-Brushless Motoren
eingestellt, lassen sich aber über den Sender (Knüppelstellung), oder das Setup Interface (siehe
Punkt 6) auch ganz einfach an die individuellen Bedürfnisse anpassen.
The X-speed controllers have an optimal default setup for Motors. It is also possible to make your own
setup with the transmitter (stick position) or the setup interface (see chapter 6).
Einstellungen im Auslieferzustand / Factory default settings:
- Bremse / brake: Aus / off
- Akku-Typ / battery type: LiPo
- Unterspannungserkennung / recognition of undervoltage: 3,2V / Zelle* / 3.2V / cell*
- Verhalten bei Unterspannung / behavior under voltage: Zurückregelung / reduce power
- Beschleunigung (Gasannahme) / acceleration: Schnell / fast
- Timing: Auto
- Frequenz / frequency: 8KHz
*mit Autodetect (Akku muss eine Spannung von min. 3,8V pro Zelle haben, sonst kann der Regler die Zellenzahl
nicht korrekt erkennt, was zu einem zu späten Abschalten und Tiefentladen führen kann).
*with autodetect (LiPo must have min. 3,8V / cell, otherwise the ESCs cannot recognize the correct count of
cells. This can lead to a too late cut off and deep discharge of the battery).
