Given below is the main screen and the respective indications for use:
Clock
Temperature:
Ambient
(ventilated)
Ambient
(Idro)
Heating
DHW
On/Off button
Button for temperature
setting
The screen shown depends on the type of heating unit connected: the above example refers to the hot air heating model.

3.2 Turning On

To turn on the stove, press P1 for a few seconds: the message START will appear on the display.
The unit carries out the startup phases in sequence according to the procedures defined by the parameters, reaching the work condition. The
various phases are indicated in the stove status area on the display.

3.3 Turning Off

To turn off the stove, press P1 for a few seconds: the message FINAL CLEANING will appear on the display. At the end of the shutdown
operation the message OFF will appear on the display.

3.4 Temperature SETTING adjustment

From the main screen, press P2 to access the temperature adjustment screen.
P1 P2
The screen shown depends on the type of heating unit connected, therefore it may not accurately reflect the manual.
3.5 Flame power and ventilation adjustment
P1 P2
Press P1 to return to the main screen or press P4 to go to the ventilation adjustment screen.
P1 P2
Button for power and ventilation
Then set the temperatures with P2 and P3. Press P1 to return to the main screen.
In addition to the ambient temperature the following temperature adjustment
screens may appear, depending on the type of heating unit.
P3
From the main screen select P3 to access the heating power adjustment screen.
Set the heating power with P1 and P2 from a minimum value of 1 to a maximum
value of 5.
P3 P4
Power status
P3 P4
setting
Idro Ventilated
Ambient (Idro)
Heating water
14
Thermostat status
(if present):
Ambient
Heating
DHW
Function status
Button for chrono and language
setting
DHW
Ambient (Ventilated)
