GB
sunlight may considerably reduce the range of the
remote control.
Objects between the remote control and the IR
receiver which can impede reception of the signal
must be avoided. Handle the remote control with
care. Do not drop it, keep it away from heat and
moisture so as not to damage the remote control.
7. Description of the remote control
functions (Fig. 2-4)
a) Key assignment
1 "ON-OFF" (equipment ON/OFF) key
2 "Mode" (operating mode) key
3 "-" (reduce temperature) key
4 "+" (increase temperature) key
5 "Fan" (fan speed) key
6 "Swing" (automatic, horizontal slat adjustment)
key
7 "Clock" (set time) key
8 "Timer ON" (equipment ON timer) key
9 "Blow" key
10 "Temp" (select temperature display) key
11 "Timer OFF" (equipment OFF timer) key
12 "Turbo" (maximum fan speed) key
13 "Sleep" (sleep function) key
14 "Light" (display light) key
b) Brief function description
1. ON/OFF: Pressing this button enables you to
switch on the device. Pressing it a second time
will switch off the device.
2. MODE: Pressing this button allows you to select
the mode for the device. The mode will change
each time you press the button in the following
sequence: AUTO – COOL – DRY – HEAT –
FAN.
3. -: Pressing this button reduces the temperature
set for the room.
4. : Pressing this button increases the temperature
+
set for the room.
5. FAN: Pressing this button enables you to select
the fan speed. Each time you press this button
the speed will be switched in the following
sequence:
LOW – MED – HIGH – AUTO.
6. SWING: Pressing this button will activate the
automatic direction change for the ventilation
flaps. The air flow is adjusted
upwards/downwards.
7. CLOCK: Pressing this button enables you to set
the current time.
8. TIMER ON: Pressing this button enables you to
set the time at which the device will switch on. To
26
30.07.2008 12:16 Uhr Seite 26
deactivate this mode, press the button as often
as required until the TIMER ON indicator
disappears from the display.
9. BLOW: Pressing this button enables you to
activate the Blow function which is designed to
prevent moisture on the heat exchanger in the
indoor device. This function is only available in
DRY and COOL modes.
10. TEMP: Pressing this key enables you to display
the set temperature, the current room
temperature or the outdoor temperature
measured by the equipmentʼs temperature
sensor.
11. TIMER OFF: Pressing this button enables you to
set the time at which the device will switch off. To
deactivate this mode, press the button as often
as required until the TIMER OFF indicator
disappears from the display.
12. TURBO: Pressing this button enables you to set
an even higher fan speed to cool or heat the
room more quickly.
13. SLEEP: Pressing this button enables you to
select economy mode. Pressing it a second time
will deactivate this mode. The mode is also
deactivated as soon as you press the ON-OFF
button. This function can only be used in COOL
and HEAT modes.
14. LIGHT: Pressing this button enables you to
switch on the display light.
Operating modes
A) Cooling mode
1. Press the "ON/OFF" key to switch on the device.
2. Press the "MODE" key until the "Cooling" mode
icon appears in the display.
3. Press the "Swing" key. The air flow is adjusted
upwards/downwards. Press the key twice to lock
the slats in their current position.
4. Press the "FAN" key to select the fan speed:
Automatic -> Slow -> Medium -> Fast
5. Press the "+" or "-" key to set the desired
temperature.
Notes!
The cooling mode will only work if the room
temperature set is lower than the current room
temperature. When the set room temperature is
reached, the outdoor compressor stops. The
centrifugal fan of the indoor device circulates the
air in the room.
The set room temperature should not be more
than 5°C below the outdoor temperature
(example: outdoor temperature 30°C, ideal room
temperature 25°C).
The room temperature can be set between 16°C
and 30°C with the remote control.
