7.2 Pressure transmitters with stainless steel cell

Accuracy
4 = 1 % FS max.
7 = 0.5 % FS max.

Mechanical connection

2 = G1/2 A DIN 3852 (male)
4 = G1/4 A DIN 3852 (male)
7 = 9/16-18 UNF 2A, SAE 6 (male)
8 = 1/4-18 NPT (male)

Electrical connection

4 = Appliance plug Binder series 714 M18, 4-pole
(connector not supplied)
5 = Appliance plug EN 175301-803 (DIN 43650), 3-pole + PE
(connector supplied)
6 = Appliance plug M12x1, 4-pole
(connector not supplied)
Signal
A = 4 .. 20 mA, 2-conductor
Pressure ranges
4-digits for bar: 0006; 0016; 0040; 0060; 0100; 0250; 0400; 0600
5-digits for psi: 00150; 00500; 00750; 01000; 01500; 03000; 05000; 06000; 09000
Modification number
SXX = with approvals for shipping
HDA 4 X X X - A - XXXXX - SXX
