original operating manual / contents
1 Safety regulationS ___________________ 2
1.1 Explanation of symbols used _____________________2
1.2 Safety hazards ________________________________2
2 introduction _________________________ 4
2.1 Legend for explanatory diagram Maxum II _________4
2.2 Applications __________________________________4
2.3 What kind of spraying materials can be applied? _____4
2.4 Technical data ________________________________4
3 PreParing the coating material ______ 5
3.1 Coating material purity _________________________5
4 Starting oPeration ___________________ 5
4.1 Setting the Maxum II spray gun __________________5
5 SPraying technique ___________________ 7
5.1 Breaks in work ________________________________7
6 finiShing work and cleaning the unit 8
7 maintenance __________________________ 9
7.1 Adjusting the packing nut _______________________9
7.2 Replacing the needle packing and air valve seals ____9
7.3 Replacing the check valve, valve seal and air tubes __11
7.4 Replacing the cup gasket ______________________11
8 changing gun modeS _________________ 12
8.1 Converting to a single pin trigger ________________12
8.2 Using a pressure feed system ___________________12
8.3 Converting the gun to a regulator gun ____________13
8.4 Converting the gun from non-bleeder to bleeder ___13
9 chooSing a Projector Set ____________ 14
9.1 Changing a projector set _______________________14
10 material reduction/Projector Set
chart ________________________________ 15
11 remedy in caSe of faultS _____________ 16
12 oPtional acceSSorieS ________________ 17
12.1 Repair kits ___________________________________17
SPare PartS liStS __________________________ 82
Spare parts list for turbine cup gun ____________________82
Spare parts list for turbine pressure feed gun ____________84
Spare parts list for regulator cup gun __________________86
Spare parts list for compressor pressure feed gun ________88
warranty _________________________________ 90
2
1

Safety regulationS

1.1

exPlanation of SymbolS uSed

This manual contains information that must be read and
understood before using the equipment. When you come to
an area that has one of the following symbols, pay particular
attention and make certain to heed the safeguard.
 This symbol indicates a potential hazard
that may cause serious injury or loss of life.
Important safety information will follow.
This symbol indicates a potential hazard

to you or to the equipment. Important
information that tells how to prevent
Attention
damage to the equipment or how to avoid
causes of minor injuries will follow.

Danger of skin burn injury
 Danger of fire from solvent and paint fumes
Danger of explosion from solvent, paint

fumes and incompatible materials
Danger of injury from inhalation of harmful

vapors
i
Notes give important information which

should be given special attention.
1.2

Safety hazardS

hazard: exPloSion hazard due
to incomPatible materialS
Will cause severe injury or property damage.
PreVention:
•
Do not use materials containing bleach or chlorine.
•
Do not use halogenated hydrocarbon solvents such as
methylene chloride and 1,1,1 - trichloroethane. They
are not compatible with aluminum and may cause an
explosion. If you are unsure of a material's compatibility
with aluminum, contact your coating's supplier.
A list of the materials used in the construction of
i
the equipment will be made available on request
to validate compatibility with the coating
materials to be used.
Maxum II
