Getting Started - WEBTEC HT Series Bedienungsanleitung

Tachometer Pressure
input gauge
Selector switch
G Display - Large analog display. Automatically turns off if the unit is unused for more than
20 minutes.
G Pressure gauge - Analog pressure gauge, filled with glycerine to ensure good dampening
when reading pulsating pressures.
G Tachometer input - Connection socket for the optional infra-red phototachometer.
G Selector switch - Turn the switch to select the required function.
G OFF/RESET - Switches the tester off and resets the unit after automatic power shut off.
G 'B' TEST - Checks the condition of the battery.
G TEMP - Temperature is indicated on the display.
G TACH - RPM is indicated on the display.
G FLOW 'HI' - Flow is indicated on the 'Hi' scale of the display.
G FLOW 'LO' - Flow is indicated on the 'Lo' scale of the display.
G Battery cover - Remove this to replace the battery.
2

Getting Started

Battery
voltage low
Battery
Display
voltage ok
(flow, temp, rpm)
Battery cover
