Compliance:
KINETEC Performa complies with the standards of Directive 93/42/EEC, and bears the CE mark.
KINETEC Performa complies with the standards in force (IEC 601.1.2) concerning the electromagnetic
compatibility of medical devices.
KINETEC Performa complies with the standards of Directives Machine n°2006/42/CE.
Description
The KINETEC Performa machine consists of the following components:
1 • Lower limb support.
2 • Thigh support.
3 • Foot support.
4 • Hand control.
5 • Thigh support setting lock.
6 • Lower limb support setting lock.
7 • Foot support positioning setting lock.
8 • Transport handle.
9 • ON/OFF switch and fuses.
10 • Liquid-crystal display.
11 • Increase / decrease keys.
12 • EXTENSION setting key.
13 • FLEXION setting key.
14 • STOP key.
15 • START key.
16 • PAUSE key.
17 • SPEED key.
18 • FORCE key.
19 • TIMER key.
20 • Reading or selecting SYNCHRO-STIMULATOR
(please request the instruction sheet from your
KINETEC distributor).
Display Details:
A • 3-character area showing the extension limit.
B • 3-character area showing the flexion limit.
C • 8-character area showing various messages (RUN,
STOP, EXT, FLEX, SPEED, FORCE, PAUSE, etc...).
D • 3-character area showing the real-time angle of the
knee; this value changes in line with the movement.
Performa
9
4
10
12
11
17
15
20
A
EN
3
1
6
7
8
16
C D
2
5
13
14
18
19
B
