ENGLISH
DD 5700 digital dual station
- DD 5700 230V
- DD 5700 120V
- DD 5700 100V
This unit allows you to connect and work with
2 tools simultaneously.
You can connect this unit to all the tools of our
Advanced series
corresponding stand, including the DR 5600
desoldering iron by adding the electric
desoldering pump MS 9004 Ref. 9004000 or the
air pressure desoldering system MS 9005 Ref.
9005000.
The station's components:
DD 5700 230V Ref. 5700200
- DD 5700 230V control unit
- Connection cable to mains
- Instructions manual
DD 5700 120V Ref. 5700100
- DD 5700 120V control unit
- Connection cable to mains
- Instructions manual
DD 5700 100V Ref. 5700110
- DD 5700 100V control unit
- Connection cable to mains
- Instructions manual
Kit DD 5700 -2245/DR 5600 230V Ref.5700230
- DD 5700 230V control unit
- MS 9004
electric desoldering pump
- DR 5600 desoldering iron
with the 5600-003 tip
- 2245 handpiece
- DR 8500 desoldering iron stand Ref. 0788500
- AD 8245 soldering iron stand
- 2245-003 cartridge
- 2245-006 cartridge
Kit DD 5700 -2245/PA 1200 230V Ref.5700232
- DD 5700 230V control unit
- 2245 handpiece
- PA 1200 micro hot tweezers
- AD 8245 soldering iron stand
- PA 8110 hot tweezers stand
- 2245-003 cartridge
- 1200-002 cartridge (2 units)
Speak to your distributor for more kits.
Ref. 5700200
Ref. 5700100
Ref. 5700110
but always using
Ref. 0269300
Ref. 0269320
Ref. 0269320
Ref. 5700200
Ref. 9004000
Ref. 5600000
Ref. 2245000
Ref. 0788245
Ref. 2245003
Ref. 2245006
Ref. 5700200
Ref. 2245000
Ref.1200000
Ref. 0788245
Ref. 0748110
Ref. 2245003
Ref. 1200002
Technical specifications
- Temperature selection from 90 to 450°C or
190 to 840°F (±5%).
- Power: 150W.
- Safety transformer, red separator and double
isolation, with an integrated temperature
protection fuse.
- DD 5700 230V control unit
its
Input: 230V 50Hz. Output: 24V.
- DD 5700 120V control unit
Input: 120V 60Hz. Output: 24V.
- DD 5700 100V control unit
Input: 100V 60Hz. Output: 24V.
- Total weight of unit: 6Kg (13,25lbs).
- ESD protected housing "skin effect".
Typical surface resistance: 10
square.
- Complies with CE standards on electrical
safety, electromagnetic compatibility and
antistatic protection.
- Equipotential connector and the tool tip are
connected to station mains ground supply for
ESD protection.
This product should not be thrown in the
garbadge.
2
Ref. 5700200
Ref. 5700100
Ref. 5700110
5 11
-10 Ohms/
