1. Before starting up the machine make sure that
the supply voltage is the same as that shown on the
specification plate.
2. Always keep hands clear of the cutting area, and
always hold the machine using the grips.
3. Always use original VIRUTEX blades. Never use blunt
or damaged blades or blades of the wrong size or in
poor condition.
Always use the original VIRUTEX blade holders and blade
supports mounted on the machine. If necessary, replace
them with original VIRUTEX parts.
4. It is necessary to work with dust collection in order
to prolong the life of the blades and prevent any
breakages.
5. Avoid cutting nails. Check the work surface before
planing.
6. Wait until the machine has come to a complete stop
before putting it down or storing it.
7. Wear earplugs when using the machine (see chapter
10)
2. TECHNICAL CHARACTERISTICS
Imput Power....................................................................700 W
Motor..............................................................................50/60 Hz
No load speed.........................................................16,500 /min
Cuts per minute...................................................................33,000
Cutting width......................................................................80 mm
Cutting depth.............................................................0-3 mm
Rabbeting depth......................................................11 mm
Weight........................................................................3.2 kg
Weighted equivalent continuous
acoustic pressure level A................................................87 dBA
Acoustic power level A....................................................98 dBA
Uncertainty..................................................................K = 3 dbA
Wear ear protection!
Vibration total values.............................................a
Uncertainty.................................................................K: 1.5 m/s
3. STANDARD EQUIPMENT
Contained in the transportation case you will find the
following elements:
1. Planer CE35E
2. Guide stop
3. Dust collector connection
4. Key for securing the blades
4. GENERAL DESCRIPTION
The CE35E planer is equipped with replaceable, twin-
use blades of hard metal, side shoes for giving depth
on recesses or gains M (Fig. 2), a guide stop for working
from references or from the side, and a safety switch
with inverse locking, which prevents accidental start
6
up of the machine.
The machine is equipped with a dust collector connec-
tion which can be used for connection to our AS182K,
AS282K dust collector or any industrial equivalent via
the STANDARD DUST COLLECTOR ATTACHMENT (ref.
6446073). For assembling the dust collector connection,
remove the chips outlet guide A (Fig. 1) using screws B
and fit the dust collector connection in its place.
5. REGULATING THE CUT
Turn knob C (Fig. 2) until the required depth is reached
(Maximum depth of cut 3 mm).
6. REPLACING THE BLADES
Changing and regulating the blades
Release screws D (Fig. 3) and slide the blade sideways
until it comes out of the blade-holder cartridge. Insert
the new blade and tighten screws D.
The machine's blade-holders are accurately adjusted
and do not normally require any further adjustment.
If, however, this becomes necessary, this is done by
adjusting screws F until the blades are parallel to the
machine base using a rule supported on the base. The
blades supplied by Virutex are reversible (double-edge).
For blade-holder system spares use only original VIRUTEX
components.
: <2.5 m/s
2
h
2
7. CHANGING THE TRANSMISSION BELT
Unscrew screws H (Fig. 4) and remove protection G.
Replace the worn belt with a VIRUTEX original spare,
taking care to fit it correctly into the pulley cogs, never
forcing it.
8. MAINTENANCE OF THE
BRUSHES AND COLLECTOR
The brushes must be replaced when they reach a minimum
length of 5 mm (Fig. 5)
Disconnect the machine from the mains
before carrying out this operation.
Ensure that screws D are correctly
tightened before resuming work with
the machine.
Disconnect from the mains before car-
rying out any maintenance operations.
