PULSEDOSE
CONSERVING DEVICE
DeVilbiss® PulseDose® Compact
EN
Conserving Device
Instruction Guide for Models:
-PD1000I for CGA 870 valve outlet
-PD1000G for German threaded valve outlet
CAUTION–USA Federal law restricts this device to sale by, or on the
order of a physician.
DANGER– NO SMOKING
Aparato de Regulación Compacto
ES
PulseDose® DeVilbiss®
Guía Instructiva para los Modelos:
- PD1000I para válvula de descarga CGA 870
- PD1000G para válvula de descarga roscada Alemana
PRECAUCIÓN– La ley federal de los EE.UU. limita la venta de este
aparato a médicso o bajo prescripción facultativa.
PELIGRO– NO FUMAR
Économiseur compact DeVilbiss®
FR
PulseDose®
Guide d'instructions des modèles :
- PD1000I pour sortie de robinet CGA 870
- PD1000G pour sortie de robinet fileté, Allemagne
ATTENTION–La loi fédérale américaine limite la vente de cet
appareil par ou sur ordonnance d'un médecin.
DANGER– INTERDICTION DE FUMER
COMPACT
®
C
LR 47089
DeVilbiss® PulseDose® Kompakt-
DE
Sauerstoff-Einspargerät
Bedienungsanleitung für Modelle:
- PD1000I mit CGA 870 Pin Index Anschluss
- PD1000G mit DIN Anschlusss
ACHTUNG–Nach US-Bundesgesetzen darf dieses Gerät nur von
einem Arzt bzw. auf Anordnung eines Arztes verkauft werden.
VORSICHT– NICHT RAUCHEN
Economizzatore compatto
IT
DeVilbiss® PulseDose®
Guida di istruzioni per i modelli:
- PD1000I per scarico valvola CGA 870
- PD1000G per scarico valvola filettato tedesco
ATTENZIONE– La legge federale statunitense limita la vendita di
questo dispositivo ai medici o su loro prescrizione.
PERICOLO– VIETATO FUMARE
DeVilbiss® PulseDose® Compact
NL
zuurstofbesparingsapparaat
Instructiehandleiding voor modellen:
- PD1000I voor klepopening CGA 870
- PD1000G voor klepopening met schroefdraad (Duitsland)
ATTENTIE– De federale wetgeving in de Verenigde Staten schrijft
voor dat dit apparaat uitsluitend mag worden verkocht of voorge-
schreven door een arts.
GEVAAR– VERBODEN TE ROKEN
US
