TermaTech TT10 Montage- Und Bedienungsanleitung Seite 20

minutes at lighting. Put about 10 kindling sticks (dia. 2-3 cm) in the bottom of the stove, laid in a
criss-cross pattern as a log house. Put 2 firelighters in the middle and light them.
2. Leave the door ajar so there is an opening of about 2-3 cm. Leave the stove like that for about
8-10 minutes before you close the door completely. Stay by the stove as long as the door is ajar.
3. When the fire has burned to embers (there are no more flames) open the door gently so the ash
is not whirled out through the door. Gently spread out the embers with a poker so they are even.
4. Put 2-3 pieces of firewood in the stove, about 1.7 kg total. The pieces are put in the bottom of
the stove and parallel to the front of the stove with equal distance to the stove's sides and with
mutual distance of about 1 cm. The front piece is best lit if it has a split side that is turned to the
door and one in the embers. Close the door completely immediately.
5. The knob/damper is opened so it is about 2/3 open (between the left and middle position) and
after about 2 minutes the damper is set to about 1/3 open. How much the damper should be open
depends on the individual chimney's draught, but the flames should now stabilise to a calm fire.
6. When the wood has burned to embers (after about 1 hour) you start again from point 3.
MAINTENANCE – always use original parts
Maintenance and cleaning of the stove should only be performed when the stove is cold.
The daily maintenance is limited, but once a year the stove should get thorough maintenance. The
combustion chamber should be cleaned for ashes and soot and the door hinges and the closing
mechanism should be lubricated with copper grease.
The surface is maintained by brushing it with a soft, long-haired brush or by using the vacuum
cleaner with a brush. The stove can also be dusted with a duster. Always remember: only when the
stove is cold.
Jointings can look okay, but they collapse under the heat and thereby lose the ability to keep the
stove sealed. Jointings should be changed as needed as it is important to good combustion and a
clean window that the stove is sealed.
The insulation plates in the combustion chamber that are broken or worn can easily be changed
as they are loosely fixed. The material used is called Vermiculite and is a porous, but very suitable
insulation material. It has no effect on the stove's efficiency that the insulation cracks. However, it
should be changed when the wear surpasses half of the original thickness.
Painting the stove with Senotherm-spray can cover spots or small scratches from kettles and such.
Larger damages needs to be ground with fine steel wool, vacuumed and then sprayed. The can has
to be shaken vigorously and then sprayed on at a distance of 15-20 cm. It is very important that the
stove is not in use and completely cold before you use the spray due to the fire hazard. In order to
keep the stove's varnished surfaces looking nice for years to come you should try to avoid touching
the varnished surfaces when the stove is hot. Make sure to have sufficient ventilation when using
spray paint.
Glass normally does not need any maintenance apart from cleaning. This is most easily done by
using TermaTech's glass cleaner. Remember only to use glass cleaner when the stove is cold. Glass
is made of ceramic glass, be sure of environmentally disposal.
Original parts which need to be changed due to wear can be found at your dealer. Because of fit
etc. only original parts from TermaTech should be used.
Right to claim compensation for defective product is under current law.
When stating deviations the use of the product must be suspended immediately and the dealer
must be contacted.
Chimney/Flues must be swept on regular occasions, as per manufacturers recommendations.
5 YEAR WARRANTY* / RIGHT TO INVOKE LACK OF CONFORMITY
If defects/faults are ascertained, use of the wood burner must be stopped immediately and the
dealer contacted.
*5 Year warranty Provided that there has been normal operation of the wood burner, Terma-
Tech offers a 5 year warranty on material and manufacturing faults on the load-bearing frame,
exclusive of the combustion chamber.
Combustion chamber: The following parts are not covered by the warranty: The combustion
chamber, Cast iron parts (bottom, door and grate), Insulation material (vermiculite plates),
Smoke deflector plates, Glass, gaskets as well as the closing mechanism/handle.
Exterior parts: The following parts are not covered by the warranty: Varnished plates/surfaces,
20
