4.2 - ID LABEL
Before using this machine make sur e that it has an ID
label. If it is without, do not use the machine and
consult your dealer immediately.
The identification label with technical specifications
is placed on the tr olley and is always visible. Check
that the electrical specifications of your power outlet
(V/Hz) are the same as those shown on the label.
1
2
3
5.1 HIGH PRESSURE CONNECTION
A
1 - Connect one end of the high pr essure hose to the end of the automatic gun (A).
2 - Complete the assembly by coupling the extension to the gun/lance and tighten firmly (B).

5 - INSTALLATION

A
8
• Replace the r ed travel plug (fig.1)
with the vented black/yellow dipstick
provided (fig.2).
• Check that the oil in the sight glass is
at the half-way level (fig.3).
B
