• Press <ENTER> to confirm your selection.
• Use <UP> or <DOWN> to set the DMX starting address.
• Press <ENTER> to confirm your selection.
DMX Channel Values
3-Channel Mode
channel
1
2
3
7-Channel Mode
channel
1
2
3
4
(channel 6 @ 032 ~ 223)
5
(channels 1 ~ 4 only)
(channel 5 controls speed
6
when channel 6 = 032 ~
7

8. Cleaning and maintenance

• All screws should be tight and free of corrosion.
• The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections ...
• Mechanically moving parts must not show any signs of wear and tear.
• The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.
• Regularly remove dust from the housing and the air vents using a slightly damp cloth.
• There are no user-serviceable parts inside. Refer to an authorized dealer for service and/or spare
parts.

Fuse Replacement

• Wedge the fuse holder out of its housing with a flat-head screwdriver.
• Remove the damaged fuse from its holder and replace with exact same type of fuse.
• Insert the fuse holder back in its place and reconnect power.
9. Troubleshooting
problem
fuse keeps blowing
chase is too slow
fixture has no power
fixture is not responding
10.01.2011
function
red
green
blue
function
red
green
blue
colour macros
speed
strobe
mode
223)
dimmer
check total load placed on fixture
check user manual for speed adjustment
check for power on mains
check fixture's fuse
check DMX settings for correct addressing
check DMX cables
check polarity switch settings
check DMX indicator on LCD display
VDPLP64SL
from to
000 255
000 255
000 255
from to
000 255
000 255
000 255
000 015
016 255
000 255
000 015
016 255
000 031
032 063 pulse 0 ~ 100% with RGB faders
064 095 pulse 100 ~ 0% with RGB faders
096 127 pulse 100 ~ 0 ~ 100% with RGB faders
128 159
160 191
192 223
224 255
000 255
possible solution
7
description
dimmer 0 ~ 100%
dimmer 0 ~ 100%
dimmer 0 ~ 100%
description
dimmer 0 ~ 100%
dimmer 0 ~ 100%
dimmer 0 ~ 100%
no function
colour macros
slow ~ fast
no function
slow ~ fast (6 Hz ~ 18 Hz)
RGB
auto fade
auto switch (3 colours)
auto switch (7 colours)
sound control
dimmer 0 ~ 100%
