Product Installation

1) Connect the power cable to the cigarette lighter. Ensure the cable is
placed around the windscreen so as not to obstruct the driver's view
and then fix it securely in place. To get the best overall shot, attach the
device between the glass and the rear-view mirror.
2) Do not install in a position which may obstruct the driver's view or dis-
tract them.
3) Some vehicles continue to supply power to the cigarette lighter, even
when the engine is turned off. If this is the case, before leaving the
vehicle, unplug the cable from the cigarette lighter.
4) When using the device for the first time, it may be low on battery. If you
cannot switch on the device due to low power, manually connect the
external power cable to charge the battery first.
5) Only use a branded microSDHC card of class 10 or higher. For optimal
recording length, we recommend using cards with a capacity of at least
8GB up to a maximum of 32GB. We recommend formatting the card
when using it for the first time.

Quick Functions

1) Display Off – tap the "ON/OFF" button
2) Video Audio – tap the "UP" arrow
3) LED Flashlight – tap the "DOWN" arrow
4) File Lock – whilst recording video, lock the current recording by tapping
the "MODE" button.
5) Motion Detection – tap the "Motion Detection" button

Icon Key

Video Mode
Loop Length
No GPS Signal
Memory Card Detected
Audio On
Exposure
Recording Locked
Photo Mode
Motion Detection
GPS Signal
Connected to Power
Audio Off
Image Stabilization
