CM charger

2
3 4
1 12 V Voltage unit
Jack for the power supply unit on the back of the CM charger.
2 Charging cradle for device components
3-pin charging cradle to hold the CM-BT unit
3 LED (red) Standby indicator
4 LED (green) Charge indicator
Installation of the CM charger
1. Plug the power supply unit into the 230 V mains.
2. Connect the CM charger to the power supply unit by inserting the round con-
nector of the power supply unit into the DC jack on the back of the CM charger.
