14
Volume button
Use this button to adjust the volume of any connected
headphone/headset/induction loop. Use this button to
adjust the volume of any connected headphones/head-
sets/induction loops. With "+" the volume is increased,
with "-" the volume is reduced.
Important: Please note the safety instructions regarding
the volume.
Mute button
Use this button to enable or mute the internal or externally
connected microphone.
Neck strap attachment
Attach the supplied neck strap by pushing the pins at the
end of the neck strap into the fastening holes. For safety
reasons, the fastening will detach when pulled strongly.
Integrated microphone
If no external microphone or headset is connected, you
can speak directly into the integrated microphone.
Maintain a distance of 10 cm from the microphone when
speaking.
Headphone/headset/induction loop connector
You can connect headphones, a headset or an induction
loop to the jack connection.
µ Microphone connector
You can connect a microphone with a 4-pin mini XLR
connector to the microphone connector (for pin assign-
ment, please refer to chapter 6 "Technical Specifications").
¸ Line-In, 3-pin jack connector 3.5 mm
You can connect an external player to the jack connector.
Unite TP – Bodypack Transmitter
