Operate the spot only after having familiarized with its functions. Do not permit operation by persons not
qualified for operating the spot. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the spot! Rather use a soft and damp cloth.
Please use the original packaging if the spot is to be transported.
Please consider that unauthorized modifications on the spot are forbidden due to safety reasons!
If this spot will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, lamp explosion, crash etc.
DESCRIPTION OF THE DEVICE
Overview
Side
5
2
3
4
6
1
12
6
6
9
10
11
7
8
(1) Clip-to-hold clamps
(2) Colour filter frame
(3) Lens housing
(4) Housing
(5) Mounting bracket
(6) Shutter
(7) Focus screw
(8) Fixation screw
(9) Lamp housing
(10) Insulated handle
(11) Fuse
(12) Ballast resistor
16/39
40002600_V_1_0.DOC
