§3.4 Instandhaltung Schweißbrenner
§3.4.1 Explosionszeichnung Brenner
4
3
2
1
3.1
1 9
1 7
1 6
§3.4.2 Stückliste Brenner
NO.
Description
1
Tip D.12 14-15AK
2
Electric nozzle 0.8/M6*25
3
15AK Goose gun neck(Hexangular adapter and Plastic adapter) 1
3.1
15AK Goose gun
4
Hexangular adapter
5
Plastic adapter
6
MIG blue handle
7
Torch Switch 21.8mm
8
Screw D.3*10
9
Handle locking ring
10
Cable fixing joint 15AK
11
Coaxial cable team /16mmq/3m
12
Cable thimble 12-16-25 MMQ
13
CO
Euro-rear thimble
2
14
Screw M4*6 UNI 6107
15
Torch locknut /plastic screw thread
16
Euro-main socket/flexibility pin
17
Feeding pipe locknut
18
Insulating feed pipe 0.6-0.8 3m, Blue
19
Spanner for the electric nozzle
STEUERUNG UND ANSCHLÜSSE
5
6
8
7
1 3
1 5
1 4
9
10
1 8
1 2
11
11
QTY.
Remark
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
