This is the set-up window, if you press the button whilst the LED's are
flashing you enter set-up, if you let the LED's flash for 2 seconds then
stop, the ESC will operate with previously input set up values.)
NOTE: If you have removed the factory fitted battery connector,
(see warranty) ensure polarity is correct.
NOTE: If you have removed the factory fitted battery connector, (see
warranty) ensure polarity is correct.
NOTE2: If LED's do not flash but instead there is a solid red LED this
indicates no signal, check transmitter is turned on & that the receiver
lead is correctly plugged into the receiver.
3. Whilst the LED's are still flashing, press the set button, this will set
your neutral position, the green LED will come on.
4. Push the throttle control to the full forward position and return to
the neutral position, (This has set maximum forward speed point) the
red LED will come on.
5. Pull the throttle control to the full brake/reverse/astern position
and return to the neutral position. (This has set the maximum brake/
reverse/astern point)
Calibration is complete!
Your SIRIUS ESC is now ready to use as it is now but if you want to
fine tune your ESC read on ...
Troubleshooting
1) My reversible speed control has no reverse?
Either go through the optional settings or simply go through the initial set up again,
this reverts the speed control back to factory settings which is reverse engaged.
2) I just get a red LED when I switch on?
You have no signal from your receiver, make sure your receiver lead is plugged into
the receiver correctly and that your crystals match.
OPTIONAL - FINE TUNING YOUR SIRIUS ESC
This part of the set-up is purely optional, if you are happy with
how your ESC is working you do not need to enter this set-up stage,
however, if you do want to adjust your ESC or want to try and get
more from your ESC, continue.......
Fine tuning set-up can be entered by pressing the set button on the
ESC and holding it down for one (1) second whilst the ESC is in the
neutral position (both the red & green LED on). Confirmation that you
have entered fine tuning set-up is by a flashing green LED. See chart
below for graphical explanation of working through the fine tuning
set up procedure.
Capacitor connection - if supplied
Connect positive wire of capacitor to positive battery post on ESC,
connect negative wire of capacitor to negative battery post on ESC.
Instruction SIRIUS ESC
LIMITED WARRANTY
Ansmann Racing guarantee this product to be free from factory defects for 24 months from purchase
date, verified by receipts. This does not cover suitability for specific applications, components worn by
use, tampering, incorrect connection, alteration to original connectors, switches or wires (apart from
the fitting of an in-line fuse), damage to batteries or other equipment through use, misuse or shipping
damage. Our liability is limited to repairing or replacing units to original specification. Our liability will
not exceed the cost of the product. By using this ESC, the user accepts all liability. We reserve the right to
modify this guarantee without notice.
