Anti-Scratch
The built-in visor features a
special coating to minimise
scratches . This coating prevents
rapid scratching of the external
part of the visor .
Construction for those who
wear glasses
The helmet is also suitable for those who wear
glasses . An extra soft padding improves the
wearing comfort for those who wear glasses .
HCM Technology
High Density Copolymer
Matrix: High quality ABS
plastic is formed under extreme heat and
pressure to make a robust and impact-resistant
outer shell .

A.I.R. ventilation system

Newly developed A .I .R .
ventilation system – with the
ventilation flaps opened, nega-
tive pressure draws out warm air .
Use and Installation
Instructions

Inner Lining

The inner lining (9) can be completely removed
and cleaned separately (see care instructions) .
To remove the inner lining loosen the neck guard
connected to the inner pad and pull the inner
pad clips out of the front of the helmet (see
Fig . A) .

Snap-Fastener System

The snap-fastener enables an individual and
quick vernier adjustment of the chin strap .
Press the snap-fastener together until the helmet is
sitting comfortably but firm (see Fig . B) .
By means of the snap at the end of the chinstrap,
the excess chinstrap can be attached to addition-
ally secure it .
14
GB

Cheek Pads

The cheek pads (7) are affixed via three press-
studs respectively in the helmet . You can easily
remove the pads (see Fig . C) .
When securing the cheek pads inside the helmet
you must hear every press stud click in .

Acoustic Damping

The acoustic damping (8) is for noise reduction,
in particular when driving at high speeds .
Press the acoustic damping into the cavity of
the cheek pads (see Fig . D) . The acoustic side
pad equipped with Velcro faces towards the
helmet shell .

Top Vent

The top vent (1) can be opened and closed by
means of a slider (see Fig . E) .
A.I.R. ventilation system
Open and close the A .I .R . ventilation system (2)
with a slide (see Fig . F) .

Visor Replacement

Removing the visor
Turn the outer covers counter-clockwise to release
(see Fig . G) . Remove the visor, being careful not
to lose the control elements . The control elements
are marked L and R .
Installing the visor
Place the visor onto the inner control element,
then press the outer control element into the
designated holder . The arrow on the control ele-
ment should point up . Be sure to place the control
element marked "L" at the left of the helmet (see
Fig . H) .
Lastly, insert the cover into the opening and se-
cure by turning a quarter clockwise turn . Be sure
the logo is correctly positioned (see Fig . I) .
