2) If your module requires values to be sent on control channel 32 and control channel 0, you will need
to press and hold the Bank Select button, and first enter the value needed for cc; 32 in the second
octave/numeric entry field. Then, while continuing to hold the Bank Select button, press the key labeled
"-/H" (indicates that what follows is the "higher byte") and then enter the value needed for cc; 0 in the
second octave/numeric entry field. When you release the Bank Select button, the messages will be sent.
The SL-990 pRO will transmit the bank change when you let go of the button.
Shape Key – Now let's consider the programming of the shapes, of the curves of the dynamics, that
is. If you want to adapt your own masterkeyboard to the response to the dynamics of the expander
or the MIDI device, or if you want to adapt the keyboard response to your own touch on the keyboard,
the SL-990 pRO in the Shape mode offers 4 different kinds of curves:
- Shape N°1 has a linear response and corresponds fairly closely to most of the MIDI devices on sale.
- Shape N°2 has a less sensitive response and you must therefore play with a little more pressure; in
some cases this can be described as more expressive; it can also be useful to use this if the Midi recei-
ving device is too sensitive.
- Shape N°3 has an even less sensitive response than the previous one.
- Shape N°4 has a less sensitive response than shape N°3.
NOTE: Together with the Bank Select command, the SL-990
pRO also sends the last Program Change
number entered. This is because not all MIDI devices will switch the bank unless they subsequently
receive a Program Change.
