Technical data

Nominal voltage
Mains frequency
Power input
Idle speed
Torque (hard / soft)
Chuck
Dimensions with depth stopper
Dimensions with auto feed attachment
Weight with depth stopper
Weight with auto feed attachment
Protection class
Table of contents
1 Power tool features .................... 13
2 Properties of tool ....................... 14
2.1 Product features ........................ 14
2.2 Intended use ............................. 14
3 Symbols ................................... 14
4 Safety instructions ..................... 14
4.1 Safety instructions specifi c
to the given tools ....................... 14
4.2 Emission levels .......................... 15
5 Power tool settings ..................... 15
5.1 Changing the direction
of rotation ................................. 15
6 Tool holder, attachments ............. 15
7 Operation ................................. 16
7.1 Switching on and off ................... 16
7.2 Depth stopper ........................... 16
7.3 Hook and clip ............................ 17
7.4 Auto feed attachment ................. 17
8 Working instructions ................... 17
9 Accessories ............................... 18
10 Environmental Protection /
Disposal.................................... 18
11 Warranty .................................. 19
12 EU Declaration of Conformity ....... 19
Drywall screwdriver DWP 4000 DEC -
GB GB
Original instruction
230 - 240 V ~
50 - 60 Hz
400 W
0 - 4000 min
-1
6 / 14 Nm
¼" DIN 3126 / ISO 1173
245 mm × 75 mm × 205 mm
345 mm × 75 mm × 220 mm
1.5 kg
1.8 kg
II /
1

Power tool features

[1-1] Bit storage
[1-2] Switch
[1-3] Forward / reverse switch
[1-4] AUTO/MAN switch
[1-5] Depth stopper
[1-6] Bit
[2-1] Mains cable
[3-1] Depth stopper
[3-2] Bit holder
[3-3] Bit
[3-4] Chuck
[3-5] Gear box
[5-1] Clip
[5-2] Screw
[6-1] Hook
[6-2] Screw
[7-1] Bit, long
[7-2] Auto feed attachment
[8-1] Depth stopper button
[8-2] Depth stopper
[8-3] Screw length scale
[9-1] Control wheel for screwing depth
[9-2] Presetting indicator
[9-3] Collated screws
[11-1] Arresting button
[11-2] Sign for dismounting the slides
[12-1] Button
[12-2] Transport lever
[12-3] Spring
The accessories shown or described do not
have to be included with the supplied tool.
